Characteristics:
1.Die head is layer type spiral mandrel, continuous 3600 rotation.
2.Screen pack changer design is reliable, safe in operation and change the fitter
screen easier.
3.Various functional parts may be installed to the lies.,such as length counting
device, vertical cutting device, cooling water row pipe, film spreading roller,
scrap collecting device.
Use:
The lines are designed developed by our corporation according to market need, they reach the advanced levels in the 90s, come up with analogous lines in home.
It is optimum designed on the trounds of preference of analogous lines in foreign and home. The lines can be blown cotinuous 800/1500mm in fold width 0.08mm
in the thickness packaging films, film has good insulation, for instance holding temperature, antihumid, antibreeze, anti-rain,anti-rost, insulation oxygen,oil
resistive, and so used for light and heavy-duty packaging, for example fresh fruits, meat-feeding,salt vegetables, fresh milk, drink.
Main Technical Variables
Model |
3SJ-G1000 |
3SJ-G1200 | 3SJ-G1500 | ||
Screw Diameter | ф55*2 ф60*1 | ф60*2 ф65*1 | ф65*2 ф70*1 | ||
Screw Ratio L/D | 28:1 | 28:1 | 28:1 | ||
Screw Speed | 15-150r/min | 15-150r/min | 15-150r/min | ||
Main Motor Power | 15Kw*2 18.5Kw*1 | 18.5Kw*2 22Kw*1 | 22Kw*2 30Kw*1 | ||
Extrusion Output(Single) | 50kg/h | 80kg/h | 100kg/h | ||
Range of Die | φ200 | φ250*1 | ф300*1 | ||
Single-sided Thickness of Film | 0.01-0.10mm | 0.01-0.10mm | 0.01-0.10mm | ||
Max. Folding Width of Film | 1000mm | 1200mm | 1500mm | ||
Electric Total Capacity | 76Kw | 88Kw | 102Kw | ||
Overall Dimension | 6600*4100*5000mm | 6800*4300*6000mm | <td bgcolor="#ffffff" height="20" valign="center
If you have any enquiry about quotation or cooperation,please feel free to email us at ray@sanbi.comor use the following enquiry form. Our sales representative will contact you soon. Thank you for your interest in our products.
