use:
Its extruder, cylinder and screw rods are made of quality alloy steel that have been nitrized and processed in a precision way. Hence it is sound in hardness, durable in corrosion resistance. The specially-designed screw is of sound quality in plasticizing, which helps increase the production capacity. It is applied to blowing the plastic films like low density polytene (LDPE), high density polytene(HDPE) and linear low density polytene (LLDPE). It is widely applied to producing the packing bags for foodstuff, clothing, rubbish bag and vest ones.
OPTIONAL EQUIPMENT:
1)AUTO LOAD
2)CAST ALUM HEATER
3)AIR SHAFT
4)DIE ROTARY DEVICE
5)BOUBLE SIDES WINDER
6)UP AND DOWN
Main Technical Variables:
Model | A50 | A55 | A65 | A65-1 |
Diameter of screw | φ50 | φ55 | φ65 | φ65 |
Rcduced diameter of film(mm) | 100-600 | 200-800 | 300-1000 | 400-1200 |
Single-face Thickness of film(mm) | 0.01-0.10 | 0.01-0.10 | 0.01-0.10 | 0.01-0.10 |
Max.Extrusion(Kg/h) |
35 |
50 |
65 |
80 |
L/D | 28:1 | 28:1 | 28:1 | 28:1 |
Power of main moto(kw) | 11 | 15 | 22 | 22 |
Power of Tracion main moto(kw) | 1.1 | 1.1 | 1.5 | 1.5 |
Heating Power(kw) | 11 | 13 | 19 | 21 |
Outline diameter(L x W x H) (mm) |
4800 x 1900 x 3800 | 5500 x 2100 x 4600 | 6500 x 2300 x 5200 | 6500 x 2500 x 5200 |
Weight(T) | 1.5T | 2T | 2.3T | 2.6T |
Technical Parameters are subject to change without prior notice!
